The following section describes the CAD-120S MkII basic specifications. The specifications are subject to change without notice or obligation.
Circuit Type Class AB, push-pull amplifier, Ultralinear or Triode mode operation with a front panel selector switch
Power Output Ultralinear – 120 watts per channel
Triode – 60 watts per channel
Inputs XLR balanced or RCA single-ended
Noise and Hum -80 dB
Input Impedance 100K both RCA and Balanced
Frequency Response 17 Hz – 25 KHz flat @ 1 watt
Tubes 2 – 6SN7 input gain stage
2 – 6SN7 driver tubes
8 – KT 88 output tubes
Power Transformer EI High voltage & bias supply EI laminate
Output Transformer(s) Special bifilar wound 150 watt rating unit in each channel
Gain 28 dB
Sensitivity 1.24v
Power Supply Capacitors 4 x 560µF
Speaker Posts Cary gold plated copper, 5-way binding
AC Cord 3 Conductor Shielded, Detachable
AC Power Requirements 117 VAC @ 50/60 Hz
234 VAC @ 50/60 Hz
Warm-Up Time 3 Minutes
Break-In Time 100 hours of playing time
Finish Anthracite black chassis with silver or black aluminum faceplate
Weight 65 lbs
Dimensions 8″ H x 17 ” W x 14″ D
