The following section describes the DAC-200ts basic specifications. The specifications are subject to change without notice or obligation.
Master Clock Jitter Below measurable levels
Digital Sampling Rates (Fs) 44.1 kHz to 768 kHz
Digital Filter 8x Oversampling Digital Filter
Digital/Analog Converters 4 – 2 channel AK4490EQ working on true balanced output
BLUETOOTH CSR Bluetooth v 4.0 with aptX® low latency audio decoder
Analog Filter 3rd Order Bessel
Analog Outputs Balanced XLR , Single – Ended RCA
Digital Outputs Coaxial, Toslink operating at Sample Frequency (Fs) from 44.1 kHz to 192 kHz, 16 bit to 24 bit
Digital Inputs USB x 1
BLUETOOTH x 1
AES/EBU x 1, Coaxial x 2, Toslink x 1
Digital Input Sample Rate USB operating at Sample Frequency (Fs) from 44.1 kHz to 384 kHz, 16 bit to 32 bit, DSD 64, and DSD 128
BLUETOOTH operating at Sample Frequency (Fs) 44.1 kHz, 16 bit
AES/EBU, Coaxial, Toslink operating at Sample Frequency (Fs) from 44.1 kHz to 192 kHz, 16bit to 24 bit
Tube Compliment 12au7 x 2
Control Trigger input 12VDC x 1
IR control x 1
Communication Ethernet RJ45 full remote configuration interface
Wi-Fi 802.11 b/g/n
Power Input Configured at factory for either 110-120 or 220-240 VAC, 50-60 Hz
Power Consumption 52 Watts
Finish Black powder coated matte chassis with silver or black aluminum faceplate
Weight 28 lbs
Dimensions 3.75″ H x 17.25″ W x 16.25 ” D
