Features
Channels 2
Current Feedback Topology Yes
Phono EQ: OP amp + FET input stage
HDAM version HDAM-SA3, SA2
Power Transformer Toroidal
High Grade Audio Components Yes
Customised Components Yes
Symmetric PCB Layout Yes
Aluminium extrusion heat sink Yes
Tone Control: Bass / Treble / Balance Yes / Yes
Source Direct Yes
Pure Modes 3
Inputs/Outputs
Audio Inputs 4
Phono Input: MM Yes
Digital In: Optical / Coaxial 2 / 1
USB-A 1 (rear)
Recorder out Yes
Pre-out Subwoofer
Power Amp Direct IN No
Gold Plated Cinch Yes
Speaker A / B No
Speaker Terminals Marantz SPKT-1+
Number of terminals 1 pair
Remote Control Bus in / out Yes
Headphone Out Yes (Front)
Network
HEOS Multi-room and Streaming / Network Audio Streaming Yes / Yes
Lossy formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless formats: FLAC / ALAC / WAV Yes / Yes / Yes
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes
DSD Audio Streaming up to DSD5.6
Gapless Playback Yes (FLAC, WAV ,ALAC ,DSD)
AirPlay 2 Audio Streaming Yes
Internet radio Yes (TuneIn)
Spotify connect / Deezer / TIDAL / Napster / Pandora / SiriusXM Yes / Yes / Yes / Yes / Yes / Yes
Support for voice control: Alexa/Google assistant / Siri Yes / Yes / Yes
Compatible with Remote APP for Smart Phones HEOS
Ethernet / Wi-Fi Yes / Yes (dual antenna/ dual band)
Bluetooth Yes
Specifications
Power Output (8 / 4 Ohm RMS) 60 W / 80 W
Frequency response 5 Hz – 100 kHz ±3 dB
Total Harmonic Distortion 0.02%
Damping Factor 100 and over
Input Sensitivity: MM 2.0 mV / 47 kΩ/kohms
Signal to Noise Ratio: MM 87 dB (5 mV input, 1 W output)
Input Sensitivity: High level 220 mV/18 kΩ
Signal to Noise Ratio: High level 115 dB (2 V input, rated output)
Others
FL Display 3 line OLED
GUI Languages English / French / Spanish
Setup Assistant Yes
Firmware Update by Network / USB Yes
Variable Cross Over Yes (40/60/80/100/120Hz)
Shield Case for Digital Circuit Yes
IR Learning for TV remote Yes
Auto Power On / Off Optical In 1 / Optical In 2 / Coaxial In (Default: OFF)
Sleep / Timer Yes
General
Available Colors SG / BK
Metal Front Panel Yes
Power Consumption 220W
Network Standby Consumption in W 4.7
Standby Consumption 0.4W
Detachable Power Cable Yes
Remote Control Yes
System Remote Function Yes
Maximum Dimensions (W x D x H) 440 x 125 x 379 mm *excluding antennas
Weight 10.8kg
