CONFIGURATION
2-way Reversed Array
/
DRIVERS
1 Tweeter 38mm T38Waveguide
1 Woofer 130 mm ROHACELL® Full-Apex™
Poly-Ring NdFeB motor
/
SENSITIVITY
87 dB SPL normalized to 1 m/2.83 Vrms/
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room
/
LOW FREQUENCY CUT OFF
60 Hz @ -3 dB referred to C4 WETS
/
/
FINISHING
Solid walnut and hdf
/
SIZE
400 x 180 x 270 mm (H x Wx D)
/
WEIGHT
8Kg ( single piece )
/
SPEAKER ORIENTATION
Speakers should be titled inward facing the
listener
/
LISTENING DISTANCE & LAYOUT
TECHNICAL DATA
S AL ES N ETW OR K S UPPOR T W OR L D W ID E / EN GL I S H
C OL L EC T ION
21.10.2020 Aviator Ghibli - Chario Audio
https://chariohifi.com/portfolios/av_ghibli/?lang=en 5/9
/
CROSSOVER FREQUENCIES
1270Hz @ -6dB (4th Order)
/
SUGGESTED AMPLIFIERS
Up to 100W/8Ω Average Power
/
RATED IMPEDANCE
Modulus 8Ω (minimum 6.2Ω @200Hz)
Argument ±36°(20Hz-20kHz)
/
LOW FREQUENCY LOAD
Down-Firing Vented
/
EAR LISTENING HEIGHT
Preferably on woofer axis
Minimum speaker-listener distance 2.0 m
A carpeted oor in front ofthe speakers is
recommended
/
WARRANTY
5 years Worldwide
/
SPARE PARTS AVAILABILITY
Allthe spare parts will be available for 15 years
after the
model will be discontinued.
