SPECIFICATIONS
CONFIGURATION
2-way Reversed Array
DRIVERS
1 Tweeter 38mm T38Waveguide
1 Woofer 165 mm ROHACELL® Full-Apex™ Poly-Ring NdFeB motor
SENSITIVITY
90 dB SPL normalized to 1 m/2.83 Vrms/
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room
LOW FREQUENCY CUT OFF
50 Hz @ -3 dB referred to C4 WETS
CROSSOVER FREQUENCIES
1180Hz @ -6dB (4th Order)
SUGGESTED AMPLIFIER
Up to 120W/4Ω Average Power
RATED IMPEDANCE
Modulus 4Ω (minimum 3.4Ω @170Hz)
More than +36° (500-1200Hz)
LOW FREQUENCY LOAD
Down-Firing port
LISTENING HEIGHT
Preferably on woofer axis
CABINET
Solid walnut and hdf
SIZE
445 x 240 x 310 mm (H x W x D)
WEIGHT
10 Kg ( single piece )
SPEAKER ORIENTATION
Speakers should be titled inward facing the listener
LISTENING DISTANCE & LAYOUT
Minimum speaker-listener distance 2.0 m
A carpeted floor in front of the speakers is recommended
WARRANTY
5 years Worldwide
