CONFIGURATION
5-way Reversed Array
/
DRIVERS
1 Tweeter 38 mm T38 Waveguide
1 Midrange 165mm ROHACELL® –FullApex™ Poly-Ring NdFeB motor
1 Woofer 165 mm ROHACELL® Full-Apex™
Poly-Ring NdFeB motor
2 Subwoofer 200mm Nat-ber NdFeB motor
/
SENSITIVITY
95 dBSPL normalized to 1m 2.83Vrms decorrelated L/R pink noise in ITU-R BS 1116-1
compliant listening room
/
LOW FREQUENCY CUT OFF
35 Hz @ -3 dB 4Ω sr referred to C4 WETS
/
CROSSOVER FREQUENCIES
Conventional crossover frequency concept
substituted by CrossoverOverlapping Range
From 150 to-200Hz
Bottom Sub-Back Sub-Woofer-Midrange
From 1kHz to 1.5kHzWoofer-MidrangeTweeter
/
SUGGESTED AMPLIFIER
Up to 250W/4Ω Average Power
/
RATED IMPEDANCE
Modulus 4Ω (minimum 3.0Ω
@174Hz) Argument ±36°(20Hz-20kHz)
/
/
/
FINISHING
Solid walnut and hdf
/
SIZE
1427 x 270 x 500 mm (H x Wx D)
/
WEIGHT
80Kg ( single piece )
/
SPEAKER ORIENTATION
Speakers should be titled inward facing the
listener
/
LISTENING DISTANCE & LAYOUT
Minimum speaker-listener distance 2.5 m A
carpeted oor in front ofthe speakers is
recommended
/
WARRANTY
5 years Worldwide
/
SPARE PARTS AVAILABILITY
Allthe spare parts will be available for 15 years
after the model will be discontinued.
