SPECIFICATIONS
CONFIGURATION
3-way Reversed Array
DRIVERS
1 Tweeter 38 mm T38 Waveguide
1 Midrange 165mm ROHACELL® –Full-Apex™ Poly-Ring NdFeB motor
2 Woofer 165 mm ROHACELL® Full-Apex™ Poly-Ring NdFeB motor
SENSITIVITY
92 dBSPL normalized to 1m 2.83 Vrms
de-correlated L/R pink noise in
ITU-R BS 1116-1 compliant listening room
LOW FREQUENCY CUT OFF
40 Hz @ -3 dB 4Ω sr referred to C4 WETS
CROSSOVER FREQUENCIES
200Hz-1235Hz @ -6dB (4th Order)
SUGGESTED AMPLIFIER
Up to 180W/4Ω Average Power
RATED IMPEDANCE
Modulus 4Ω (minimum 3.6Ω @95Hz) Argument ±36° (20Hz-20kHz)
LOW FREQUENCY LOAD
Down-Firing Vented
EAR LISTENING HEIGHT
Preferably on midrange axis
CABINET
Solid walnut and hdf
SIZE
1045 x 235 x 390 mm (H x W x D)
WEIGHT
30 Kg ( single piece )
SPEAKER ORIENTATION
Speakers should be titled inward facing the listener
LISTENING DISTANCE & LAYOUT
Minimum speaker-listener distance 2.5 m
A carpeted floor in front of the speakers is recommended
WARRANTY
5 years Worldwide
