Specifications
Type All-in-one Player
Amplifier Output 150Watts 8Ω @ 0.1 % THD+N
250Watts 4Ω @ 0.1% THD+N
Analogue inputs 2 x RCA pairs
2 x 5-pin DIN
Analogue outputs 1 x Stereo power amplifier
1 x 4-pin DIN
1 x RCA pair
1 x 3.5mm headphone jack
USB 2 x USB Type A Socket (front and rear – 1.6A charge)
Digital inputs (S/PDIF) 2 x Optical TOSLINK (up to 24bit/96kHz)
2 x Coaxial RCA (up to 24bit/192kHz, DoP 64Fs)
1 x BNC (up to 192kHz, DoP 64Fs)
1 x HDMI ARC
Streaming Chromecast Built-In, Apple AirPlay2, TIDAL, TIDAL Connect, Spotify® Connect, Qobuz, Bluetooth® (AptX HD), Internet Radio, UPnP™ (hi-res streaming), Roon Ready.
Multiroom Connectivity Serve up to 4 network-connected players via UPnP™ at full CD quality. Party Mode Streaming: Sync up to six Uniti or other Naim streamers, and control via the Focal & Naim app.
Audio Format WAV - up to 32bit/384kHz
FLAC and AIFF - up to 24bit/384Hz
ALAC (Apple Lossless) - up to 24bit/384Hz
MP3 - up to 48kHz, 320kbit (16 bit)
AAC - up to 48kHz, 320kbit (16 bit)
OGG and WMA - up to 48kHz (16 bit)
DSD - 64 and 128Fs
Gapless playback supported on all formats
Frequency response 5Hz to 25kHz (-3dB)
Burst power 2Ω
(1kHz for 20mS, repeat 500mS IHF) 725W
Peak current into 1Ω (1kHz 1mS) 25A
THD+N at 2/3rds full power 8Ω @1kHz <0.005%
Input signal for clipping At default:
Digital inputs: -10.6dBfs (max. sensitivity: -18.25dBfs)
Analogue inputs: 770mV (max. sensitivity: 65mV)
Signal to noise ratio ref 1W 8Ω A-weighted 61dB
Signal to noise ratio ref 100W 8Ω A-weighted 81dB
Damping factor into 8Ω 43
Control Focal & Naim app control (iOS and Android), Bi-directional ZigBee remote
Updates Update your system wirelessly via the Focal & Naim app.
Network Ethernet (10/100Mbps), Wi-Fi antennas (802.11 b/g/n/ac) built into heatsink (patent GB2524815B)
Typical use consumption 120W
(Power consumption will vary depending on the size and type of attached USB devices)
Network standby mode consumption <2W
Standby mode consumption <0.5W
Mains Supply 115V or 230V.50/60Hz
Dimensions (HxWxD) 4.56x17x10.43" (11.6x43.2x26.5cm)
Weight 33.3lbs (15.1kg)
Specifications
|
|
| Type |
All-in-one Player |
| Amplifier Output |
150Watts 8Ω @ 0.1 % THD+N
250Watts 4Ω @ 0.1% THD+N |
| Analogue inputs |
2 x RCA pairs
2 x 5-pin DIN |
| Analogue outputs |
1 x Stereo power amplifier
1 x 4-pin DIN
1 x RCA pair
1 x 3.5mm headphone jack |
| USB |
2 x USB Type A Socket (front and rear – 1.6A charge) |
| Digital inputs (S/PDIF) |
2 x Optical TOSLINK (up to 24bit/96kHz)
2 x Coaxial RCA (up to 24bit/192kHz, DoP 64Fs)
1 x BNC (up to 192kHz, DoP 64Fs)
1 x HDMI ARC |
| Streaming |
Chromecast Built-In, Apple AirPlay2, TIDAL, TIDAL Connect, Spotify® Connect, Qobuz, Bluetooth® (AptX HD), Internet Radio, UPnP™ (hi-res streaming), Roon Ready. |
| Multiroom Connectivity |
Serve up to 4 network-connected players via UPnP™ at full CD quality. Party Mode Streaming: Sync up to six Uniti or other Naim streamers, and control via the Focal & Naim app. |
| Audio Format |
WAV - up to 32bit/384kHz
FLAC and AIFF - up to 24bit/384Hz
ALAC (Apple Lossless) - up to 24bit/384Hz
MP3 - up to 48kHz, 320kbit (16 bit)
AAC - up to 48kHz, 320kbit (16 bit)
OGG and WMA - up to 48kHz (16 bit)
DSD - 64 and 128Fs
Gapless playback supported on all formats |
| Frequency response |
5Hz to 25kHz (-3dB) |
Burst power 2Ω
(1kHz for 20mS, repeat 500mS IHF) |
725W |
| Peak current into 1Ω (1kHz 1mS) |
25A |
| THD+N at 2/3rds full power 8Ω @1kHz |
<0.005% |
| Input signal for clipping |
At default:
Digital inputs: -10.6dBfs (max. sensitivity: -18.25dBfs)
Analogue inputs: 770mV (max. sensitivity: 65mV) |
| Signal to noise ratio ref 1W 8Ω A-weighted |
61dB |
| Signal to noise ratio ref 100W 8Ω A-weighted |
81dB |
| Damping factor into 8Ω |
43 |
| Control |
Focal & Naim app control (iOS and Android), Bi-directional ZigBee remote |
| Updates |
Update your system wirelessly via the Focal & Naim app. |
| Network |
Ethernet (10/100Mbps), Wi-Fi antennas (802.11 b/g/n/ac) built into heatsink (patent GB2524815B) |
| Typical use consumption |
120W
(Power consumption will vary depending on the size and type of attached USB devices) |
| Network standby mode consumption |
<2W |
| Standby mode consumption |
<0.5W |
| Mains Supply |
115V or 230V.50/60Hz |
| Dimensions (HxWxD) |
4.56x17x10.43" (11.6x43.2x26.5cm) |
| Weight |
33.3lbs (15.1kg) |
