D/A-Converter
PCM: Double-Differential-Quadruple Converter up to 32 Bit/768 kHz
DSD: T+A True 1-Bit Converter, native Bitstream up to DSD 1024 (49,2 MHz)
Digital Inputs
USB Audio Input, AES-EBU, BNC, Coax, TOS-Link, HDMI (optional)
USB Receiver conforming to UAC2 and UAC3 standards
Digital Section
Separate PCM und DSD signal paths and processing
Additional „Non Oversampling“ DAC mode (NOS-DAC)
Amplifier
Double Mono „State of the Art“ discrete HV Amp technology
Pure Class A power stage
3 separately switchable outputs (Pentaconn, XLR, 6.3 barrel socket)
Adjustable output impedance
Frequency response + 0 / − 3 dB
0,1 Hz – 200 kHz
Special Features
Complete galvanic separation between digital and analogue section
