Specifications
POWER AMPLIFIER
Impedance 8Ω 4Ω 2Ω
Power Output (per channel)
(Continuous, 20 Hz - 20 kHz, <1% THD) 400 W 600 W 800 W*
* Maximum 3 seconds due to high current draw.
THD (400 W) 0.0007% (1 kHz), 0.004% (20 kHz)
IMD (300 W)
ITU-R (19 kHz + 20 kHz) 0.0006%
SMPTE (60 Hz + 7 kHz) 0.0016%
SNR (IEC-A, ref. 400 W) 121 dB
Frequency Response (20 Hz - 20 kHz) ± 0.1 dB
Power Bandwidth (-3 dB at 400 W into 8 ohms) 91 kHz
Slew Rate 30 V/μs
Damping Factor (20 Hz - 1 kHz) 360
Channel Separation 101 dB (100 Hz), 98 dB (10 kHz)
Input Impedance 10kΩ (RCA), 15kΩ (XLR)
Input Sensitivity (for 400W into 8Ω) 2.1 Vrms
Voltage Gain 29 dB
POWER REQUIREMENT
120 V version: In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz.
220-240 V version: In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz.
POWER CONSUMPTION
Standby 310 mW
Idle 65 W
Typical Playback Levels 150 W - 300 W
High Playback Levels 600 W - 1100 W
DIMENSIONS
Height 6-3/4” (17.2 cm)
Width 17” (43.2 cm)
Depth (not including power cord) 18-1/2” (47 cm)
Weight (unpacked) 60 lb (27.3 kg)
