Spec
Rated output 150W + 150W (8Ω)/at stereo
300W + 300W (4Ω)/at stereo
600W (8Ω)/at monaural
Instantaneous max. output 1,200W + 1,200W (1Ω)/at stereo
2,400W (2Ω)/at monaural
Input sensitivity 1.24V/150W (8Ω)
GAIN 29.0dB
Input impedance Unbalanced 51kΩ
Balanced 28kΩ
Frequency response 20Hz to 20kHz (+0, -0.1dB)
1Hz to 130kHz (+0, -3.0dB)
Total harmonic distortion 0.003% or less (1kHz/8Ω)
0.04% or less (20Hz to 20kHz/8Ω)
S/N ratio (IHF-A) 117dB
Amplification feedback circuit LIFES 1.0
Output configuration 3 stage Darlington 4 paralleled push-pull
Damping factor 600
Power consumption 540W
290W (under no signal)
1.0W (at standby)
External dimensions 440(W) x 224(H) x 488(D) mm
front side knob of 2mm and rear side terminal
of 38 mm included in depth
Net weight 48.4kg
Accessories Trigger cable (Modular/3.5mm Monaural)
Power cable
Spec
Rated output 150W + 150W (8Ω)/at stereo
300W + 300W (4Ω)/at stereo
600W (8Ω)/at monaural
Instantaneous max. output 1,200W + 1,200W (1Ω)/at stereo
2,400W (2Ω)/at monaural
Input sensitivity 1.24V/150W (8Ω)
GAIN 29.0dB
Input impedance Unbalanced 51kΩ
Balanced 28kΩ
Frequency response 20Hz to 20kHz (+0, -0.1dB)
1Hz to 130kHz (+0, -3.0dB)
Total harmonic distortion 0.003% or less (1kHz/8Ω)
0.04% or less (20Hz to 20kHz/8Ω)
S/N ratio (IHF-A) 117dB
Amplification feedback circuit LIFES 1.0
Output configuration 3 stage Darlington 4 paralleled push-pull
Damping factor 600
Power consumption 540W
290W (under no signal)
1.0W (at standby)
External dimensions 440(W) x 224(H) x 488(D) mm
front side knob of 2mm and rear side terminal
of 38 mm included in depth
Net weight 48.4kg
Accessories Trigger cable (Modular/3.5mm Monaural)
Power cable
