Specifications
Name Value
Rated output power 2 x 50 W, stereo
Total harmonic distortion < 0.75% (f = 1 kHz, rated output power)
Frequency response 30 Hz – 100 kHz (-3 dB, rated output power)
Input sensitivity 425 mV, unbalanced input
Number of input ports 3 unbalanced input per channel, 1 balanced input per channel
Number of output ports 1 output terminal pair per channel, 1 line level output per channel
Gain +33.5 dB (8 Ohm); +25.5 dB (4 Ohm)
Input impedance 10 kOhm
Nominal load impedance 4 Ohm and 8 Ohm
Output polarity non-inverting
Signal-to-noise ratio > 95 dB; output noise less, than 1 mV
Power requirements 300 W
Tubes required 4 x KT120; 4 x E88CC/6922; 2 x Tungsram ECC83
Weight 25 kg
Dimensions 35 x 21 x 40 cm
