Spec
Rated output 120W + 120W (8Ω)
220W + 220W (4Ω)
Input sensitivity/
input impedance PHONO (MM): 2.5mV/47kΩ
PHONO (MC-H): 0.3mV/100Ω
PHONO (MC-L): 0.1mV/40Ω
LINE: 180mV/47kΩ
BAL.LINE: 180mV/79kΩ
MAIN IN: 1.1V/47kΩ
Output voltage PRE OUT: 1V
Frequency response PHONO: 20Hz to 20kHz (±0.5dB)
LINE: 20Hz to 100kHz (within -3dB)
Total harmonic distortion 0.007% or less (8Ω, 1kHz)
0.03% or less (8Ω, 20Hz to 20kHz)
S/N ratio (IHF-A) PHONO (MM): 87dB or more
PHONO (MC-H): 70dB or more
PHONO (MC-L): 62dB or more
LINE: 106dB or more
Volume adjustment LECUA-EX
Amplification feedback circuit LIFES 1.0
Output configuration Bipolar 4-parallel push-pull
Damping factor 330
Max. amount of tone control BASS: ±8dB at 100Hz
TREBLE: ±8dB at 760Hz
TREBLE: ±8dB at 10kHz
Power supply 230V~(50Hz) / 115V~(60Hz)
Power consumption 390W
150W (under no signal), 0.5W (at standby)
External dimensions 440(W) x 193(H) x 463(D) mm
front side knob of 20mm and rear side terminal
of 37mm included in depth
Net weight 29.4kg (main unit)
