Spec
Rated output 100W + 100W (8Ω),
150W + 150W (4Ω)
Input sensitivity/
input impedance PHONO (MM): 2.5mV/47kΩ
PHONO (MC): 0.3mV/100Ω
LINE: 180mV/47kΩ
BAL.LINE: 180mV/55kΩ
MAIN IN: 1V/47kΩ
Output voltage PRE OUT: 1V
Frequency response PHONO: 20Hz to 20kHz (±0.5dB)
LINE: 20Hz to 100kHz (within -3dB)
Total harmonic distortion 0.009% or less (8Ω, 1kHz)
0.09% or less (8Ω, 20Hz to 20kHz)
S/N ratio (IHF-A) PHONO (MM): 87dB or more
PHONO (MC): 70dB or more
LINE: 104dB or more
Volume adjustment LECUA
Amplification feedback circuit LIFES 1.0
Output configuration Bipolar parallel push-pull
Damping factor 200
Max. amount of tone control BASS: ±8dB at 100Hz
TREBLE: ±8dB at 10kHz
Power supply 230V~(50Hz) / 115V~(60Hz)
Power consumption 330W
90W (under no signal), 0.5W (at standby)
External dimensions 440(W) x 178(H) x 454(D) mm
front side knob of 20mm and rear side terminal
of 27mm included in depth
Net weight 22.5kg (main unit)
Accessories Remote control (RA-17A)
Power cable
Speaker terminal
Supported Y-lug terminal
dimension Width of part a: 15mm or less
Width of part b: 8mm or more
Spec
Rated output 100W + 100W (8Ω),
150W + 150W (4Ω)
Input sensitivity/
input impedance PHONO (MM): 2.5mV/47kΩ
PHONO (MC): 0.3mV/100Ω
LINE: 180mV/47kΩ
BAL.LINE: 180mV/55kΩ
MAIN IN: 1V/47kΩ
Output voltage PRE OUT: 1V
Frequency response PHONO: 20Hz to 20kHz (±0.5dB)
LINE: 20Hz to 100kHz (within -3dB)
Total harmonic distortion 0.009% or less (8Ω, 1kHz)
0.09% or less (8Ω, 20Hz to 20kHz)
S/N ratio (IHF-A) PHONO (MM): 87dB or more
PHONO (MC): 70dB or more
LINE: 104dB or more
Volume adjustment LECUA
Amplification feedback circuit LIFES 1.0
Output configuration Bipolar parallel push-pull
Damping factor 200
Max. amount of tone control BASS: ±8dB at 100Hz
TREBLE: ±8dB at 10kHz
Power supply 230V~(50Hz) / 115V~(60Hz)
Power consumption 330W
90W (under no signal), 0.5W (at standby)
External dimensions 440(W) x 178(H) x 454(D) mm
front side knob of 20mm and rear side terminal
of 27mm included in depth
Net weight 22.5kg (main unit)
Accessories Remote control (RA-17A)
Power cable
Speaker terminal
Supported Y-lug terminal
dimension Width of part a: 15mm or less
Width of part b: 8mm or more
