Amplification
Line In, Speaker Out (Analog bypass on)
Continuous output power into 8 ohms and 4 ohms>180W (ref. 20 Hz-20 kHz at rated THD, both channels driven)THD (20 Hz – 20 kHz)<0.02% (250 mW to 180 W, 8 ohms and 4 ohms)Signal/Noise Ratio>95 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)Clipping power210W (at 1 kHz 0.1 % THD)IHF dynamic power8 ohms: 217 W4 ohms: 400 W2 ohms: 506.4 WPeak output current>26 A (in 1 ohm, 1 ms)Damping factor>150 (ref. 8 ohms, 20Hz to 6.5kHz)Frequency Response±0.3 dB (20 Hz – 20 kHz)Channel Separation>90dB (1 kHz)>75dB (10 kHz)Input sensitivity (for 180 W in 8 ohms)Line In: 201 mVDigital In: 10.25% FS
Preamplifier
Line Input, Pre Out (Analog bypass on)
THD (20Hz-20kHz)<0.002 % at 2 V outSignal/Noise Ratio>106dB (IHF; A-weighted, ref. 500 mV out, unity gain)Channel Separation>100dB (1 kHz); >90 dB (10 kHz)Input Impedance (R and C)56 kohms + 100 pFMaximum Input Signal>4.6 Vrms (ref. 0.1 % THD)Output ImpedanceSource Z + 320 ohmsInput Sensitivity65mV (ref. 500 mV out, Volume maximum)Frequency Response±0.3 dB (20 Hz – 20 kHz)Maximum voltage output – IHF load>>5 V (ref. 0.1 % THD)
Phono
Phono Input, Pre Out (Analog bypass on)
THD (20Hz-20kHz)<0.01% at 2 V outSignal to Noise Ratio>84dB (200 ohms source; A-weighted, ref. 500 mV out)Input Impedance (R and C)46 kohms/100 pFInput Sensitivity1.08mV (ref. 500 mV out, Volume maximum)Frequency Response*±0.3 dB (20 Hz – 20 kHz)Maximum Input Signal at 1kHz>80 mVrms (ref. 0.1 % THD)
Headphone
Line Input, Headphone Out (Analog bypass on)
THD (20Hz-20kHz)<0.005% at 1V outSignal/Noise Ratio>107 dB (32 ohms loads; A-WTD, ref. 1V out, unity gainFrequency Response±0.3 dB (20 Hz – 20 kHz)Channel Separation>62 dB at 1kHzOutput Impedance2.2 Ohms
General Specifications
Supports bit rate/sample rateup to 24 bit/192 kHzFrequency band2.402G- 2.480GMaximum transmit power (dBm)7 dBm ± 2 dBm
Weight & Dimensions
Gross dimensions (W x H x D) **435 x 120 x 390mm(17 1/8 x 4 3/4 x 15 3/8)”Net Weight11.2kg (24.7lb)Shipping Weight13.6kg (30lb)
