FEATURES
3 x RCA line inputs
1 x Pair analogue XLR inputs
MM phono input
aptX Bluetooth input
Circuit-switchable headphone output
High quality internal DAC circuit (USB Amplifier only)
Rear-located USB type-B port (USB Amplifier only)
High audiophile grade components used throughout
Top quality transformer design for optimum power
Striking design and superlative build quality
Brightness-adjustable oversize LED display
Inputs 3 x RCA line inputs
1 x Pair analogue XLR inputs
1 x USB type-B input 24/192 & DSD compatible (only operational with ‘USB’ Version)
MM phono input
aptX Bluetooth input
MM input – gain, 76.75dB@1kHz, input impedance 47k ohm, 150pF
Line & XLR inputs – input impedance 24k ohm XLR, 40k ohm RCA
Gain @ 1kHz, 8ohm 36,75dB
THD @ 1W, 8ohm, 5kHz < 0.02%
@ 12W, 8ohm, 5kHz < 0.035%
Power output @ 1kHz, 8ohm > 150W
@ 1kHz, 4ohm > 230W
Frequency response @ -3dB, 12W, 8ohm from < 20Hz to more than 80kHz
Channel balance @ 1kHz, 8ohm, 12W better than 0.3dB
Cross talk @ 1kHz, 8ohm < -104dB
S/N @ 1kHz, 8ohm, 1W > 76dB
Dimensions (H x W x D) 140 x 440 (inc. faceplate) x 309mm / 140 x 400 (chassis) x 309mm
Weight 14kg
Rated Power Consumption 480W
Maximum Power Consumption 800W
