Marantz PM6007 Specs
Amplifier
Amplifier Type Integrated Amplifier (Preamp/Power Amp Combo)
Channels 2.0
Power Output per Channel 45 W at 8 Ohms (RMS)
60 W at 4 Ohms (RMS)
Frequency Response 10 Hz to 50 kHz (8 Ohms)
THD 0.008% (20 Hz to 20 kHz, 8 Ohms, Both Channels Driven)
Speaker Impedance 4 to 16 Ohms
Tone Control Bass (50 Hz): ±10.0 dB
Treble (15 kHz): ±10.0 dB
Damping Factor 100 (8 Ohms, 40 Hz to 20 kHz)
Connectivity
Rear A/V Inputs 4 x Stereo RCA
1 x Stereo RCA (Phono) with Ground Screw
2 x Optical TOSLINK
1 x Digital Coaxial
Rear A/V Outputs 1 x RCA Subwoofer
1 x Stereo RCA
Front I/O 1 x 1/4" / 6.35 mm Headphone Output
Headphone Output Power 50 mW into 32 Ohms
Other Rear I/O 1 x RCA (Remote) Input
1 x RCA (Remote) Output
1 x 1/8" / 3.5 mm (IR) Input
Speaker Connectors 4 x Binding Post Pair
Input Impedance Phono (MM): 47 Kilohms
Line: 20 Kilohms
Input Sensitivity Phono (MM): 2.2 mV
Line: 200 mV
Max Input Level Phono: 100 mV
Phono RIAA EQ Deviation ±1 dB (20 Hz to 20 kHz)
Rated Output / Impedance Subwoofer Pre-Out: 2.8 V /
Signal to Noise Ratio 102 dB
Phono (MM): 83 dB
Line, Network: 102 dB (2 V Input)
Wireless Connectivity
Wi-Fi None
Bluetooth None
Power
AC Input Power 120 VAC, 60 Hz
Power Consumption Active: 155 W
Standby: 0.3 W
Physical
Dimensions (W x H x D) 17.3 x 4.1 x 14.5" / 43.9 x 10.4 x 36.8 cm
Weight 16.7 lb / 7.6 kg
Packaging Info
Package Weight 22.6 lb
Box Dimensions (LxWxH) 20 x 18.8 x 7"
Marantz PM6007 Specs
Amplifier
| Amplifier Type |
Integrated Amplifier (Preamp/Power Amp Combo) |
| Channels |
2.0 |
| Power Output per Channel |
45 W at 8 Ohms (RMS)
60 W at 4 Ohms (RMS) |
| Frequency Response |
10 Hz to 50 kHz (8 Ohms) |
| THD |
0.008% (20 Hz to 20 kHz, 8 Ohms, Both Channels Driven) |
| Speaker Impedance |
4 to 16 Ohms |
| Tone Control |
Bass (50 Hz): ±10.0 dB
Treble (15 kHz): ±10.0 dB |
| Damping Factor |
100 (8 Ohms, 40 Hz to 20 kHz) |
Connectivity
| Rear A/V Inputs |
4 x Stereo RCA
1 x Stereo RCA (Phono) with Ground Screw
2 x Optical TOSLINK
1 x Digital Coaxial |
| Rear A/V Outputs |
1 x RCA Subwoofer
1 x Stereo RCA |
| Front I/O |
1 x 1/4" / 6.35 mm Headphone Output |
| Headphone Output Power |
50 mW into 32 Ohms |
| Other Rear I/O |
1 x RCA (Remote) Input
1 x RCA (Remote) Output
1 x 1/8" / 3.5 mm (IR) Input |
| Speaker Connectors |
4 x Binding Post Pair |
| Input Impedance |
Phono (MM): 47 Kilohms
Line: 20 Kilohms |
| Input Sensitivity |
Phono (MM): 2.2 mV
Line: 200 mV |
| Max Input Level |
Phono: 100 mV |
| Phono RIAA EQ Deviation |
±1 dB (20 Hz to 20 kHz) |
| Rated Output / Impedance |
Subwoofer Pre-Out: 2.8 V / |
| Signal to Noise Ratio |
102 dB
Phono (MM): 83 dB
Line, Network: 102 dB (2 V Input) |
Wireless Connectivity
| Wi-Fi |
None |
| Bluetooth |
None |
Power
| AC Input Power |
120 VAC, 60 Hz |
| Power Consumption |
Active: 155 W
Standby: 0.3 W |
Physical
| Dimensions (W x H x D) |
17.3 x 4.1 x 14.5" / 43.9 x 10.4 x 36.8 cm |
| Weight |
16.7 lb / 7.6 kg |
Packaging Info
| Package Weight |
22.6 lb |
| Box Dimensions (LxWxH) |
20 x 18.8 x 7" |
