Specifications
Continuous output power into 8 ohms and 4 ohms 100W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
THD (20 Hz – 20 kHz) <0.03% (250 mW to 100 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio >95dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power >115 W (at 1 kHz 0.1 % THD)
IHF dynamic power 8 ohms: 180 W, 4 ohms: 250W, 2 ohms: 300 W
Peak output current >20A (in 1 ohm, 1 ms)
Frequency response ±0.3 dB (20 Hz – 20 kHz)
HybridDigital UcD Amplifier
Optional MDC2 port for Apple AirPlay 2, Spotify Connect, and Tidal Connect
Optional MDC2 BluOS-D module adds BluOS Hi-Res multi-room music streaming and Dirac Live room correction
Network connectivity Gigabit Ethernet RJ45 Wi-Fi 5
USB 1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals
Bluetooth quality aptX HD 5.0
Bluetooth connectivity Two-Way (Receive and Headphone modes)
High-performance 32-bit/384kHz Texas Instruments differential DAC
Ultra-low-noise MM phono stage with infrasonic filtering circuitry
One optical, one coaxial digital input
HDMI-eARC input
One set of line-level analogue inputs with low-noise buffer amplifiers
Speaker A/Speaker B outputs
Subwoofer output
Dedicated headphone amplifier
Supplied accessories include an IR remote control and a calibrated microphone for Dirac Live setup
CI-Friendly – IR remote, 12V Trigger out, IR in
Seamless integrations with smarthome control systems such as Control4, Crestron, RTI, URC, Push, Lutron, iPort, and Elan
Gross dimensions (W x H x D) 435 x 110 x 355mm 17 1/4 x 4 3/8 x 14 inches
Net weight 10 kg (22 lbs)
Shipping weight 12.6 kg (27.8 lbs)
