FREQUENCY RESPONSE
+/-0.15dB 20Hz – 20kHz; +/-3.0dB 6Hz – 192kHz.
THD+NOISE
Less than .002% at 2V RMS 1kHz Balanced output.
SIGNAL TO NOISE
>114dB.
IMD + NOISE
.001% (SMPTE ratio)
CHANNEL SEPARATION
107dB.
INTRINSIC JITTER
<10pS.
DAC RESOLUTION
24 bits.
PUSH BUTTONS
Power, Menu, Option, Enter, Input, Mute.
OUTPUT IMPEDANCE
500 Ohms balanced, 250 Ohms SE.
DIGITAL FILTER
Selectable Fast or Slow algorithms.
UPSAMPLING
All Inputs upsample to 384kHz.
INPUTS
USB2.0HS 44.1 to 384kHz, DSD, 2xDSD; RCA, BNC, XLR 44.1 to 192kHz; TOS 44.1 to 96kHz.
RATED OUTPUTS
3.8V RMS Max Balanced; 1.9V max SE (@ 0dB input).
POWER SUPPLIES
Electronically-regulated low and high voltage supplies. Line regulation better than .01%.
NOISE
-103dB
TUBE COMPLEMENT
(2) 6H30 dual triodes.
POWER REQUIREMENTS
100-125VAC 60Hz (200 – 250VAC 50/60Hz) 60 watts maximum.
STAND BY
Less than 2 watt.
DIMENSIONS
Width: 19″ (48 cm)
Height: 7″ (17.8 cm)
Depth: 15.5″ (39.4 cm)
Handles extend 1.50″ (3.8 cm) forward of the front panel.
Weight: 32.0 lbs. (14.6 kg) Net; 43.2 lbs. (19.8 kg) Shipping.
