DIGITAL INPUTS
S/PDIF 24bit 44.1-192k PCM , DoP DSD64
AES/EBU 24bit 44.1-192k PCM, DoP DSD64
USB 32bit 44.1-384k PCM, DSD64-512
HD-Link1 (LVDS) 32bit 44.1-384k PCM, DSD64-512
HD-Link2 (LVDS) 32bit 44.1-384k PCM, DSD64-512
OUTPUTS (Wavedream Edition)
THD+N (at - 6dB): 0.003% or -90 dB S/N ratio (0 dB): 122 dB Dynamic range: 122 dB Output impedance: 0.5 ohms Max. voltage: 6.6Vpp(SE); 13.2Vpp(XLR)
OUTPUTS (Wavedream Signature)
THD+N (at -6db): 0.0008% or -102 dB S/N ratio (0 dB): 132 dB Dynamic range: 132 dB Output impedance: 0.5 ohms Max. voltage: 10Vpp(SE); 20Vpp(XLR)
Digital processing:
High-frequency asynchronous capture digital inputs: 560MHz sampling
Memory-based PLL, digital domain only: 300 fS jitter
Custom digital filters: linear, minimum and hybrid phase, 16x
Filter type: (advanced convolution) Parks-McClellan, 4820 taps
Mathematical precision: 68 bit INTEGER
Stopband attenuation: - 145 dB
Passband ripple: 0,0001 dB
Dither: Triangular shaped distribution
Volume control: custom multiplier array, 256 steps, 0.5 dB step
Miscellaneous:
128x64 yellow oled display, dimmable in 8 steps
4 control switches
IR remote control
Firmware upgrade via usb
Dimensions: 440 x 360 x 90 mm
Weight (net): 7.8 Kg
