Spec
Supported discs CD (CD-R, CD-RW, MQA-CD)
Supported sampling
frequencies USB input (PCM) : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz,
352.8 kHz, 384 kHz (16, 24, 32-bit)
USB input (DSD) : 2.8 MHz, 5.6 MHz, 11.2 MHz (1-bit)
Coaxial / Optical input : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz,
192 kHz (16, 20, 24-bit)
Analog output
voltage / impedance Unbalanced : 2.4 V / 300 Ω, Balanced : 2.4 V / 600 Ω, DSD : 1.7 V
Frequency response CD : 5 Hz to 20 kHz (+0, -1.0 dB)
Coaxial / Optical : 5 Hz to 47 kHz (+0, -3.0 dB)
USB : 5 Hz to 47 kHz (+0, -3.0 dB)
Total harmonic distortion CD : 0.003 %, Coaxial / Optical : 0.002 %, USB : 0.002 %
S/N ratio (IHF-A) CD : 101 dB, Coaxial / Optical : 114 dB, USB : 113 dB
D/A converter Texas Instruments PCM1795 (monaural mode) x 2
Power supply 230 V～(50 Hz) / 115 V～ (60 Hz)
Power consumption 18W
Dimensions 440(W) x 133(H) x 410(D) mm
front side knob of 2 mm and rear side terminal of 8 mm included in depth
Net weight 13.2 kg
Accessories Remote control (RD-28), Power cable
