Spec
Digital input Network : 1000 Base-T (gigabit · ethernet)
HDMI : PCM 2 channel, 4K pass-through ARC (Audio Return Channel) supported
Digital output USB (USB2.0), OPT, COAX
HDMI : PCM 2 channel, 4K pass-through ARC (Audio Return Channel) supported
Storage connection USB x 2 terminals (USB2.0, single partition, FAT32, exFAT, NTFS)
Supported sampling
frequencies USB : PCM 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz, 705.6 kHz, 768 kHz (16, 24, 32-bit)
DSD : 2.8 MHz, 5.6 MHz, 11.2 MHz, 22.5 MHz (1-bit)
COAX / OPT / HDMI (ARC) : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz (16, 24-bit)
Corresponding format formats WAV, AIFF, FLAC, ALAC, MQA, MP3, AAC, DSD (DSF, DFF)
Streaming protocols UPnP (OpenHome), TIDAL Connect, Spotify Connect, Roon Ready
Power supply 230 V～(50 Hz) / 115 V～ (60 Hz)
Power consumption 27 W (HDMI in/output when connected to USB storage)
5.9 W (HDMI in/output when USB storage is disconnected)
Dimensions 440(W) x 92(H) x 398(D) mm
front side display of 3 mm and rear side terminal of 13 mm included in depth
Net weight 10.3 kg (main unit)
Accessories Remote control (RC-30), Power cable
