SYSTEM
Closed box loading, single driver, active subwoofer
SPEAKERS
1 x 320mm (12”), 8 ohm, very long throw, sandwich honeycomb cone, wide rubber surround
AMPLIFICATION
High performance, class AB amplifier
850 W
FREQUENCY RESPONSE
20 Hz (@- 6dB, acoustic Linkwitz 4th order roll-on, default setting) to Fc (user continuously adjustable)
MAINS INPUT VOLTAGE
Selectable, 100-120Vac – 50/60Hz or 220-240 Vac – 50/60 Hz
FUSE
T12A H 250V (100-120 Vac – 50/60Hz)
T6.3A H 250V (220-240 Vac – 50/60 Hz)
CONTROLS
Direct access Master volume; APP control featuring: 4 selectable presets, volume, continuously adjustable crossover frequency (40 to 150Hz , filtering slope 24dB/oct); continuously adjustable signal phase (0° to 360°); up to 8 parametric EQ filters, Delay (1 to 20 ms); automatic room calibration; selectable auto power on/off
AUDIO SIGNAL INPUTS
2 x Line level, left and right/LFE RCA phono plugs (unbalanced)
2 x Line Level, left and right/LFE XLR plugs (balanced)
1 x High level, Neutrik 4-pole Speakon© plug
POWER CONSUMPTION
< 2 W (Stand-by)
1.200 W peak
DIMENSIONS (HXWXD)
455 x 448,5 x 448,5 mm
18 x 17,6 x 17,6 in
Including feet
WEIGHT
32 Kg
70,5 lb
