Technical Specifications
Type
Closed box, front-firing driver
Active Driver Size & Material
15 in. (380mm) long throw, carbon fiber cone with inverted carbon fibre centre cap, die cast alloy chassis
Passive Radiator Size & Material
N/A
Low Frequency Extension
15Hz at -6 dB Low Frequency
Input Connectors
High Level Neutrik Speakon, Low Level (2) RCA, (1) LFE RCA, (1) LFE XLR
Output Connectors
High Level Neutrik Speakon, (1) Low Level RCA, (1) LFE XLR, (1) Line XLR
Power Output
1,000 watts (RMS)
Amplifier Type
NextGen 7 Class D
Wireless Capability
REL AirShip II (sold separately)
Dual Parametric Filter
Yes
Finish
Piano Black Lacquer, 12 coats
Protection System
Fully Electronic Set Safe
Yes
D.C. Fault
Yes
Output Short
Yes
Mains Input Voltage
220-240 volts, 110-120 volts for certain markets
Fuses
7 Amp semi delay 230 volts operation, 15 Amp semi delay 115 volts operation
