Specifications
TYPE
(2) Front-firing active drivers, (1) rear passive, (1) down-firing passive
ACTIVE DRIVER SIZE & MATERIAL
(2) 12 in., 300mm long-throw, Continuous CastAlloy™ cone structure, cast chassis
PASSIVE RADIATOR SIZE & MATERIAL
(2) 12 in., 300mm Carbon/Carbon flat cone structure, steel chassis
LOW FREQUENCY EXTENTION
-6dB at 18 Hz
INPUT CONNECTORS
High Level Neutrik Speakon, Low Level stereo RCA, LFE XLR and LFE RCA
OUTPUT CONNECTORS
High Level Neutrik Speakon, LFE RCA, LFE XLR
POWER OUTPUT
1,000 watts (RMS)
AMPLIFIER TYPE
NextGen5 Class D
WIRELESS CAPABILITY
Yes- REL AirShip system [required]. Sold separately.
Protection System
FULLY ELECTRONIC SET SAFE
Yes
D.C. FAULT
Yes
OUTPUT SHORT
Yes
MAINS INPUT VOLTAGE
220-240 volts, 1120-120 volts for certain markets
FUSES
7 Amp semi delay 220 volts operation, 15 Amp semi delay 120 volts operation
Dimensions
W X H X D
14 1/4in., x 33in., x 20 1/4 in., (362 x 838 x 514.5mm)
NET WEIGHT
128 lbs. (58 kg)
FINISH
Piano Black Lacquer
Supplied Accessories
MAINS LEAD
Yes
NEUTRIK SPEAKON
Yes (10 Meters Nominal)
INTERCONNECT
N/A
USERS MANUAL
Yes
