Specification sheet for Sub part 2
System: Twin opposed driver, closed box, active DSP subwoofer
Analog inputs: 2 x balanced XLR, 2 x unbalanced RCA phono
Analog outputs: 2 x balanced XLR, 2 x unbalanced RCA phono
Frequency response (±3dB): 16Hz – 230Hz
Auto ON/OFF: Yes
Box Principle: Sealed
Low Pass Filter: Adjustable/preset
Phase Adjustment: 0/180 degrees
Specification sheet for Sub part 1
Woofer: 2 x 23cm MSP + hybrid drive
Amplifier power: 500W
AC power input: 100 - 120V/220 - 240V 50/60Hz
Standby power consumption: <0.5W
Maximum power consumption: 490W
Weight: 21.5kg / 45.2lb
Dimensions (W x H x D): 447 x 300 x 268mm
Dimensions with feet /grille (W x H x D): 470 x 333 x 268mm
