CONSTRUCTION DETAILS Resonance-optimised body, highly compressed wood chassis, core of natural medium-density wood fibre within an aluminium surround and upper layer incorporating a high tech synthetic compound
SPEED RANGES 33 ⅓, 45 and 78 rpm
DRIVE UNIT Decoupled and resonance damped DC motor, flat belt-drive and plug-in power supply unit designed for worldwide use with all networks and power frequencies
BEARING Polished and tempered steel shaft in a sintered bronze bushing, runs on a mirror of Teflon
PLATTER Synthetic material, CNC-precision milled surface, 30mm thickness / 1.18 inch. Aluminium subplatter.
SPEED ACCURACY (MEASURED) ± 0.05 %
POWER CONSUMPTION Max. consumption: 5.5 Watt
Off mode: 0.0 Watt
OF THE INTEGRATED PHONOPREAMP BY 1KHZ +52 dB (MM mode)
+72 dB (MC mode)
AMPLIFICATION OF THE INTEGRATED PHONOPREAMP BY 1KHZ < 0,02 % (MM mode)
< 0,03 % (MC mode)
THD OF THE INTEGRATED PHONOPREAMP -74 dB (MM mode)
-64 dB (MC mode)
S/N OF THE INTEGRATED PHONOPREAMP ± 0,5 dB
RIAA ACCURACY OF THE INTEGRATED PHONOPREAMP 47 kOhm
MAX. OUTPUT VOLTAGE OF THE INTEGRATED PHONOPREAMP < 10V
TOTAL WEIGHT Approx. 7.6kg (incl. tonearm and cartridge)
DIMENSIONS (W/D/H in mm) Approx. 420 x 350 x 125 (with tonearm)
WARRANTY 2 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
