CONSTRUCTION DETAILS:
Resonance-optimised chassis shape
Made of bullet proof wood and aluminium with precision CNC machined surface
All turntable feet are finely adjustable
Playback with three tonearms possible
SPEED OPTIONS: 33 ⅓, 45, 78rpm
DRIVE UNIT:
High torque 24V DC motor exclusively made for Clearaudio; Optical Speed Control (OSC) in real time through infrared sensor
Decoupled DC motor in chassis; resonance damping device; belt-driven
Magnetic decoupling of turntable and addtional drive platter
BEARING:
Clearaudio patented ceramic magnetic bearing (CMB) in main platter / upper drive platter assembly
Inverted bearing in lower drive platter
PLATTER: 70mm / 2.75 inch main platter, made out of synthetic material with high-density and excellent dimension stability // precision CNC machined surface, solid stainless steel sub-platter, dynamically balanced
SPEED ACCURACY (MEASURED): < ± 0.05%
POWER CONSUMPTION: Max. consumption: 9.5 watts
Consumption in operation: 4.1 watts
Standby mode: 2.4 watts
Off mode: 0.0 watts
TOTAL WEIGHT: Approx. 60kg (without tonearm and power supply)
DIMENSIONS (W/D/H): Approx. 18.11 × 19.09 × 15.59 inches (with tonearm base, without tonearm)
DIMENSIONS (W/D/H): Approx. 460 × 485 × 396mm (with tonearm base, without tonearm)
MANUFACTURER’S WARRANTY: 5 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
