CONSTRUCTION DETAILS:
Resonance-optimised chassis shape
Made of laminated wood and aluminium with precision CNC machined surface
All turntable feet are fine adjustable
Optical Speed Control (OSC)
IMS – Innovative Motor Suspension
(Suspension design of the motor using 18 O-rings)
SPEED OPTIONS: 33 ⅓, 45, 78rpm
DRIVE UNIT:
High torque 24V DC motor with belt drive
Fully automatic self-calibration of the speed by a push of a button
Hybrid engine control:
A high resolution 12 bit digital-to-analog converter (DAC) generates a motor reference voltage, which is fed into the purely analog motor control.
Automatic compensation of friction and temperature changes on the platter bearings and belts.
The speed remains in the perfect range at all times.
BEARING: Clearaudio CMB ceramic magnetic bearing in main platter.
Inverted bearing in lower drive platter.
PLATTER: 50mm / 1.97 inch main platter, made out of synthetic material with high-density and excellent dimension. //
15mm / 0.59 inch stability, precision CNC machined surface, solid stainless steel sub-platter, dynamically balanced.
SPEED ACCURACY (MEASURED): ± 0.05%
POWER CONSUMPTION: Max. consumption: 5.0 watts
Consumption in operation: 2.1 watts
Off mode: 1.8 watts
TOTAL WEIGHT: approx. 22kg (without tonearm and power supply)
DIMENSIONS (W/D/H): Approx. 495 × 343 × 180mm
(with tonarm base, without tonearm)
DIMENSIONS (W/D/H): Approx. 19.49 × 13.50 × 7.09 inches
(with tonarm base, without tonearm)
MANUFACTURER WARRANTY: 5 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
CONSTRUCTION DETAILS:
Resonance-optimised chassis shape
Made of laminated wood and aluminium with precision CNC machined surface
All turntable feet are fine adjustable
Optical Speed Control (OSC)
IMS – Innovative Motor Suspension
(Suspension design of the motor using 18 O-rings)
SPEED OPTIONS: 33 ⅓, 45, 78rpm
DRIVE UNIT:
High torque 24V DC motor with belt drive
Fully automatic self-calibration of the speed by a push of a button
Hybrid engine control:
A high resolution 12 bit digital-to-analog converter (DAC) generates a motor reference voltage, which is fed into the purely analog motor control.
Automatic compensation of friction and temperature changes on the platter bearings and belts.
The speed remains in the perfect range at all times.
BEARING: Clearaudio CMB ceramic magnetic bearing in main platter.
Inverted bearing in lower drive platter.
PLATTER: 50mm / 1.97 inch main platter, made out of synthetic material with high-density and excellent dimension. //
15mm / 0.59 inch stability, precision CNC machined surface, solid stainless steel sub-platter, dynamically balanced.
SPEED ACCURACY (MEASURED): ± 0.05%
POWER CONSUMPTION: Max. consumption: 5.0 watts
Consumption in operation: 2.1 watts
Off mode: 1.8 watts
TOTAL WEIGHT: approx. 22kg (without tonearm and power supply)
DIMENSIONS (W/D/H): Approx. 495 × 343 × 180mm
(with tonarm base, without tonearm)
DIMENSIONS (W/D/H): Approx. 19.49 × 13.50 × 7.09 inches
(with tonarm base, without tonearm)
MANUFACTURER WARRANTY: 5 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
