CONSTRUCTION DETAILS: Aluminium, stainless steel and bullet proof wood
SPEED OPTIONS: 33 ⅓, 45, 78rpm
DRIVE UNIT:
High-torque 24V DC motor exclusively made for Clearaudio; Optical Speed Control (OSC) in real time through infrared sensor
Decoupled DC motor in chassis; resonance damping device; belt-driven
Magnetic decoupling of turntable and addtional drive platter
BEARING:
Clearaudio patented ceramic magnetic bearing (CMB) in main platter / upper drive platter assembly
Inverted bearing in lower drive platter
PLATTER: 98mm / 3.86 inch main platter, made out of synthetic material with high-density and excellent dimension stability // precision CNC machined surface, solid stainless steel sub-platter, dynamically balanced
SPEED ACCURACY (MEASURED): < ±0.03%
POWER CONSUMPTION: Max. consumption: 19 watts
Consumption in operation: 8 watts
Off mode: 0.0 watts (if main switch is in ‚0‘ position)
TOTAL WEIGHT: Approx. 350kg (without tonearm and power supply)
DIMENSIONS (W/D/H): Approx. 27.17 × 24.41 × 52.17 inches (with TT1 tonearm)
DIMENSIONS (W/D/H): Approx. 690 × 620 × 1325mm (with TT1 tonearm)
MANUFACTURER’S WARRANTY: 10 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
