CARTRIDGE SPECIFICATIONS
Cartridge Type
Moving Magnet
Output Level
4mV at 1kHz
Load Impedance
47k Ohms
Frequency Response
12Hz to 30kHz
Channel Separation
30dB at 1kHz
Compliance
12 x 10-6 cm/dyne
Recommended Tracking Force
2.0 g
Channel Difference
Less than 1dB at 1kHz
Total Mass
6.5 g
Stylus
Elliptical
Cantilever Material
Aluminum
TONEARM SPECIFICATIONS
Bearing
Lateral type bearing
Arm Tube
Damped machined aluminum
Counterweight
Concentric
Adjustments
None
TURNTABLE SPECIFICATIONS
Playback Speeds
33-1/3 and 45 rpm
Motor Type
Permanent magnet AC synchronous
Speed Control
Manual speed change via a 2 speed pulley
Platter
Aluminum
Platter Bearing
Oil bath bearing with a high performance polyetheretherketone (PEEK) thrust disc and machined graphite impregnated brass bushings
Signal To Noise Ratio
35dB - 40dB
Wow & Flutter
0.1%
CONNECTIVITY
Stereo Outputs Unbalanced
1 (bridged to AMP IN)
Stereo Inputs Unbalanced
1
Digital Coaxial Input
1
Digital Optical Input
1
Subwoofer Output
1
Wireless Input
High Definition Bluetooth 4.2
CONTROL
Power Control Input
0
Power Control Output
1
Platter Light
N/A
Speed Control Fine Adjustment
No
ELECTRONIC SPECIFICATIONS
Power Output per Channel
50 Watts into 8 Ohms
80 Watts into 4 Ohms
Number of Channels
2
Speaker Impedance
4 or 8 Ohms
Rated Power Band
20Hz to 20kHz
Total Harmonic Distortion
0.5% (Amplifier)
0.2% (Preamplifier)
Dynamic Headroom
1.0dB (8 Ohms)
1.3dB (4 Ohms)
Frequency Response +0,-0.7dB
20Hz to 20kHz
Signal To Noise Ratio (Moving Magnet)
75dB
Signal To Noise Ratio (High Level)
90dB
Damping Factor
8 Ohms: >200
4 Ohms: >100
Maximum Output (Balanced / Unbalanced)
9V Unbalanced
GENERAL SPECIFICATIONS
Dust Cover Included
No
WEIGHTS & DIMENSIONS
Dimensions (W x H x D)
19-1/4” (48.9cm) x 6-3/4” (17.15cm) x 14” (35.6cm)
Weight
33.5 lbs (15.2 kg)
Shipping Weight
40.5 lbs (18.4 kg)
