Spec
Input sensitivity/
Input impedance Unbalanced 180mV/45kΩ
Balanced 180mV/90kΩ
Output/Input
impedance Unbalanced rating 1V/90Ω, max. 14.1V
Balanced rating 1V/180Ω, max. 28.7V
Frequency response 20Hz to 20kHz (+0, within -0.1dB)
5Hz to 110kHz (+0, within -3.0dB)
Total harmonic distortion Unbalanced 0.005% (20Hz to 20kHz)
Balanced 0.003% (20Hz to 20kHz)
S/N ratio (IHF-A) Unbalanced 129dB
Balanced 132dB
Volume control LECUA-EX
Amplification feedback circuit LIFES 1.0
Max. change amount of
tone control BASS: ±8dB at 100Hz
TREBLE: ±8dB at 10kHz
Remote control functions Operation, Dimmer, Input selector
Output mode (Unbalanced, Balanced, Bi-amp)
Balanced phase switching
Channel preset (Balanced phase setting, Input level
offset setting, Bi-amp output level setting)
External pre-amplifier input
Line straight, Loudness, Volume up/down, Mute
Zoom display
Power consumption 40W, 2.6W (at standby)
External dimensions 440(W) x 130(H) x 434(D) mm
front side knob of 16mm and rear side terminal
of 15mm included in depth
Net weight 19.8kg (main unit)
Accessories Remote control (RA-20), Power cable
