FB – Fully Balanced – State-of-the-art fully balanced and fully discrete tube phono stage with MC step-up transformer



NEW fully balanced throughout all stages: Input, gain, EQ, sub-sonic, output

NEW fully balanced real tube amplification – not just tube-buffer or single ended tube usage

NEW balanced XLR input for MM & MC cartridges

NEW 4x ECC83 and 4x ECC88 tubes

Semi-crystalline hydrocarbon polypropylene film capacitors instead of previously used MKP capacitors in gain and RIAA stage

Ultra-low loss factor, highest frequency and temperatur stability and longevity

Fully discrete MM & MC phono stage design

Lundahl step-up transformer for MC stage

Rectifying circuitry uses special diodes with noise suppressing resistors

Fully split-passive RIAA equalisation

Power supply with custom made toroidal transformer comes in separate matching box

External PSU s exterior aluminium case redesigned to match the main phono stage unit s look

Dimmable & colour changeable tube LED backlighting

Magnetic side panel options: high gloss Makassar or piano Black

Available in silver or black




E.A.T. E-Glo FB Phono Stage + PSU technical information

Model E.A.T. E-Glo FB Phono Stage + PSU

Color options Black, Silver

Magnetic side panel options          Piano Black, High Gloss Makassar Wood

Input impedance MC / 72dB 10, 18, 43, 75, 150, 300, 600, 1200 Ohm

Input impedance MC / 77db 2, 5, 10, 20, 40, 80, 150, 300 Ohm

Load capacity           50, 150, 270, 370, 520, 620, 740, 840 pF

Output impedance   150 ohms

Gain MM        48dB / 42dB (XLR / RCA Out)

Gain 1 MC      77dB / 71dB (XLR / RCA Out)

Gain 2 MC      72dB / 66dB (XLR / RCA Out)

Signal to noise Ratio MM 85dBV (100dBV – IEC -A), MC 77dBV (96dBV – IEC -A)

THD MM / MC 0,05% / 1V RMS

RIAA accuracy          within 0,3dB/20Hz – 20kHz

Subsonic       12dB/Octave

Power supply 230V/115 VAC selectable on the back panel, 50/60Hz /52VA

Input   RCA, XLR

Output           RCA, XLR

Power consumption 80 VA maximum, <0.5 W in standby

E.A.T. E-Glo FB Phono Stage Dimensions W × H × D      395 × 86 × 262 mm

E.A.T. E-Glo FB Phono Stage Weight          5.3 Kg

E.A.T. E-Glo FB PSU Dimensions W × H × D           395 × 61 × 280 mm

E.A.T. E-Glo FB PSU Weight  5.4 Kg
