CONFIGURATION
3-way Reversed Array
/
DRIVERS
1 Tweeter 38mm T38Waveguide
2 Woofer 130 mm ROHACELL® Full-Apex™
Poly-Ring NdFeB motor
/
SENSITIVITY
90 dB SPL normalized to 1 m/2.83 Vrms/ decorrelated L/R pink noise in ITU-R BS 1116-1
compliant listening room
/
LOW FREQUENCY CUT OFF
58 Hz @ -3 dB referred to C4 WETS
/
CROSSOVER FREQUENCIES
/
/
FINISHING
Solid walnut and hdf
/
SIZE
189 x 558 x 310 mm (H x Wx D)
/
WEIGHT
12Kg ( single piece )
/
SPEAKER ORIENTATION
Speakers should be titled inward facing the
listener
/
LISTENING DISTANCE & LAYOUT
Minimum speaker-listener distance 2.0 m A
carpeted oor in front ofthe speakers is
recommended
TECHNICAL DATA
S AL ES N ETW OR K S UPPOR T W OR L D W ID E / EN GL I S H
C OL L EC T ION
21.10.2020 Aviator Balbo - Chario Audio
https://chariohifi.com/portfolios/av_balbo/?lang=en 4/6
Midwoofer-TweeterCrossover @ 1850Hz
Woofer-TweeterCrossover @ 1300Hz
SUGGESTED AMPLIFIER
Up to 120W/4Ω Average Power
/
RATED IMPEDANCE
Modulus 4Ω (minimum 3.9Ω @185Hz) More
than +36°(500-1200Hz)
/
LOW FREQUENCY LOAD
Back-Firing Vented
/
EAR LISTENING HEIGHT
Preferably on woofer axis
