Technical specifications
Speaker (front)
1″ pure ceramic tweeter (upgradable to Diamond)
7.5″ ceramic bass/midrange
Speaker (back)
9″ Aluminium passive radiator
Crossover components
Ceramic version
Polypropylene capacitors and copper foil inductors
Diamond edition
Copper foil capacitors and copper foil inductors
Frequency range
36-40000 Hz +-2dB
Power rating
200 W
Sensitivity
88 dB/2.83 V
Impedance
6 ohms (3.1 Ohms min)
Type
2-way
Crossover frequency
Multi diverse order,
2200 Hz
Terminals
Single-wiring
WBT Nextgen
Internal wiring
Jorma
Cabinet
35 mm M-board
Piano Walnut, Matte Walnut or Piano Black
Stands and feet (optional)
Matte Black with mirror polished
Marten Isolators
35-28 x 75 x 40 cm
(13.8- 11 x 29.5 x 15.7")
21 kg (46 lbs)
Dimensions W x H x D
22-28 x 42 x 36 cm
(8.7-11 x 16.5 x 14.2")
Net weight
18 kg (40 lbs)
