EDGE-TO-EDGE HORN FOR ROOM FILLING SOUND
Experience a wider soundstage through our exclusive 90° x 90° Tractrix®
horn that never loses clarity, even at high volumes. Tell your neighbors
we’re not sorry.
PLAYS WELL WITH OTHERS SO YOU NEVER STOP STREAMING
Games in 4K. Binge-worthy TV. The best new music. With an integrated
phono pre-amp, Bluetooth® wireless technology, digital optical, analog RCA
and USB inputs, the R-50PM connects easily to all your favorite devices.
IMMERSIVE BASS WITHOUT THE SUB
The R-50PM produces dynamic bass EQ, immersing the listener in incredible
acoustics no matter the volume. Engineered with extra cabinet depth for
warmer bass and more impactful sound, you won’t need a subwoofer. (But
if you want to rock more bass later, we’ve included a simple sub-out line for
seamless integration.)
INCREDIBLE ACOUSTICS WITH A SMALL FOOTPRINT
Custom designed to maximize system performance and eliminate the need
for external amplification, you can skip the audio video receiver. These
powered monitors fit on your bookshelf, computer desk, gaming rig, or home
entertainment center. Save space without compromising sound quality.
CLASSIC COPPER, WORLD CLASS SOUND
Spun-copper thermoformed crystal polymer (TCP) woofers use steeper
angling of cones for a smoother response and better crossover integration
for improved accuracy and transparency. Our low-profile magnetic grille
gives you the option of a sleek black exterior…or a vision in copper.
TURNTABLE READY BLUETOOTH®
WIRELESS TECHNOLOGY
TV READY
NO RECEIVER NEEDED
SIMPLE SETUP
PC READY
SPECIFICATIONS
SYSTEM DESCRIPTION Powered Monitor (pair)
FREQUENCY RESPONSE 55Hz – 20kHz
DYNAMIC BASS EXTENSION 44Hz
MAXIMUM OUTPUT 104dB
TOTAL SYSTEM POWER 120W Total System Power (240W Peak)
60W per channel cont. @ <%1 THD
HIGH FREQUENCY DRIVER 1” (2.5cm) Aluminum LTS tweeter mated to 90° x 90° square
Tractrix® horn
LOW FREQUENCY DRIVER Single 5.25” (13.3cm) spun-copper TCP woofer
CROSSOVER FREQUENCY 1663 Hz (Passive)
ENCLOSURE MATERIAL MDF
ENCLOSURE TYPE Bass-reflex via rear-firing port
INPUTS
• Bluetooth® wireless technology
• Phono/Line analog (with switch and ground screw terminal)
• 3.5mm analog mini jack
• USB digital
• Optical digital
OUTPUTS Single RCA line level output for connection to subwoofer
HEIGHT, WIDTH, DEPTH 14” (35.6 cm), 7” (17.8 cm), 10.8” (27.4 cm)
WEIGHT 24.8 lbs (11.2 kg)
FINISH Black
VOLTAGE 100V-240V 50/60Hz internal power supply with region specific
power cords
INCLUDED ACCESSORIES
• Remote control (with 2 x AAA batteries)
• 4M speaker wire with soldered tips
• 2M power cord (region specific)
• 2M USB Type A to Type B cable
