Specification
System
Frequency response
40 Hz - 30 kHz ± 6 dB
Recommended amplifier power
20 - 200 W
Power handling (IEC)
100 W continuous, 400 W peak
Sensitivity
89 dB (1 W @ 1 m)
Impedance
8 Ω
Components
Low frequency dual concentric
1 x 10" (254 mm) paper pulp cone with twin roll impregnated fabric surround, 52 mm (2") edge wound voice coi
High frequency dual concentric
1 x 1.3" (33 mm) aluminium/magnesium alloy dome with edge-wound voice coil
Crossover
Frequency
1.2 kHz
Type
Bi-wired, hard wired passive, low loss 2nd order low pass, 1st order high pass
Adjustment
±3 dB over 1 kHz to 30 kHz shelving,
2 dB to -6 dB per octave
over 5 kHz to 30 kHz slope
User controls
treble roll off, treble energy
Enclosure
Type
Twin distributed port
Connectors
5 x 4 mm 24ct Tannoy customized binding posts
Dimensions HWD
350.5 x 309 x 523.2 mm (13.8 x 12.2 x 20.6")
Net weight
18.5 kg (40.8 lbs)
Construction
19 mm (3/4") Particle Board, MDF with plywood internal bracing - heavily damped
Finish
Walnut veneer and high acoustic transparency nylon grill cover
Accessory pack (included)
Bi-wire bridge connectors
Tannoy High End Loudspeaker Wood Wax
Rubber feet
