Specifications
Type 3-way loudspeaker
Drivers
1 1/8” (28mm) RASC™ Évo soft-dome tweeter with ARID technology, aluminum back chamber, neodymium magnet, and optimized ventilation
3” (75mm) RASC™ Évo soft-dome midrange with ARID+ technology, double suspension, enhanced chamber design, and advanced cooling
15” (380mm) BSC™ (Basalt Sandwich Construction) woofer with optimized ventilation, large 3-inch voice coil, and an extended excursion
Frequency Response (-6 dB) 23Hz – 24kHz
Sensitivity (2.83V/1m) 90dB/2.83V/ 1 metre
Nominal Impedance 6 ohms
Minimum Impedance 4.4 ohms at 74Hz
Crossover Frequency 340Hz and 2.25kHz
Recommended Amplifier Power Power handling: 300 watts. Starting from 30-50 watts.
Recommended Room Size 35 to 80 m² (377 to 861 ft²)
Dimensions (H*W*D)
With stand: 1160 mm x 456 mm x 480 mm (67 in x 17.95 in x 18.90 in)
Without stand: 820 mm x 456 mm x 480 mm (32.28 in x 17.95 in x 18.90 in)
Net Weight
With Stand: 67 kg (147.71 lbs)
Without Stand: 54,6 kg (126.55 lbs)
