Speaker System
Speaker Configuration 3-Way
Recommended Amplifier Power 40 to 250 W
Drivers 1x 1" / 25.4 mm Magnesium/Aluminum Alloy Tweeter
1x 6.5" / 165.1 mm Cone Midrange
2x 6.5" / 165.1 mm Cone Woofer
Passive Radiators No
Enclosure Type Bass-Reflex
Ports 1x Front-Firing
1x Down-Firing
Frequency Response 45 Hz to 30 kHz (±3 dB)
Frequency Range 37 Hz to 30 kHz (-6 dB)
Impedance 8 Ohms
Magnetic Shielding No
Inputs/Outputs 1x Binding Post Pair Input
Crossover Low-Pass:
290 Hz
High-Pass:
2400 Hz
Sensitivity 91.5 dB
Input Impedance 8 Ohms
Physical
Color High-Gloss Black
Environmental Protection No
Placement & Mounting Options Floorstanding (with Included Hardware)
Floor Contacts Metal Spikes
Cabinet Material MDF
Grille Cloth (Removable)
Dimensions 11.6 x 40.7 x 14.6" / 294 x 1035 x 371 mm
Weight 55.1 lb / 25.0 kg
Speaker System
| Speaker Configuration |
3-Way
|
| Recommended Amplifier Power |
40 to 250 W
|
| Drivers |
1x 1" / 25.4 mm Magnesium/Aluminum Alloy Tweeter
1x 6.5" / 165.1 mm Cone Midrange
2x 6.5" / 165.1 mm Cone Woofer
|
| Passive Radiators |
No
|
| Enclosure Type |
Bass-Reflex
|
| Ports |
1x Front-Firing
1x Down-Firing
|
| Frequency Response |
45 Hz to 30 kHz (±3 dB)
|
| Frequency Range |
37 Hz to 30 kHz (-6 dB)
|
| Impedance |
8 Ohms
|
| Magnetic Shielding |
No
|
| Inputs/Outputs |
1x Binding Post Pair Input
|
| Crossover |
Low-Pass:
290 Hz
High-Pass:
2400 Hz
|
| Sensitivity |
91.5 dB
|
| Input Impedance |
8 Ohms
|
Physical
| Color |
High-Gloss Black
|
| Environmental Protection |
No
|
| Placement & Mounting Options |
Floorstanding (with Included Hardware)
|
| Floor Contacts |
Metal Spikes
|
| Cabinet Material |
MDF
|
| Grille |
Cloth (Removable)
|
| Dimensions |
11.6 x 40.7 x 14.6" / 294 x 1035 x 371 mm
|
| Weight |
55.1 lb / 25.0 kg
|
