TECHNICAL SPECIFICATIONS
Type 3-way loudspeaker
Drivers
1 1/8” (28mm) soft-dome tweeter equipped with Revival Audio ARID (Anti Reflection Inner Dome) patented technology with a large back chamber and low resonance frequency of 650Hz
5 1/4” (13.5cm) BSC (Basalt Sandwich Construction) midrange driver
2 of 7” (18cm) BSC (Basalt Sandwich Construction) woofers
Frequency Response (+/-3db) 38Hz – 26kHz (-3dB)
Sensitivity (2.83V/1m) 89dB/2.83V/ 1 metre
Nominal Impedance 4 ohms
Minimum Impedance 3.2 ohms at 120Hz
Crossover Frequency 550Hz and 3.0kHz
Recommended Amplifier Power Power handling: 200 watts. Starting from 30-50 watts.
Recommended Room Size 30 to 60m2
Dimensions (H*W*D) 1200 mm x 345 mm x 395 mm
Net Weight 38 kg. (83.75 lbs.)
