Specification
System
Frequency response
35 Hz – 30 kHz ± 6 dB
Recommended amplifier power
20 - 300 W
Power handling (IEC)
150 W continuous, 600 W peak
Sensitivity
93 dB (1 W @ 1 m)
Impedance
8 Ω
Components
Low frequency dual concentric
1 x 15" (380 mm) paper pulp cone with twin roll impregnated fabric surround, 52 mm (2") edge wound voice coil
High frequency dual concentric
1 x 1.3" (33 mm) aluminium/magnesium alloy dome with edge-wound voice coil
Crossover
Frequency
1.1 kHz
Type
Bi-wired, hard wired passive, low loss 2nd order low pass, 1st order high pass
Adjustment
±3 dB over 1 kHz to 30 kHz shelving,
±3 dB over 1 kHz to 5 kHz shelving,
2 dB to -6 dB per octave
over 5 kHz to 30 kHz slope
User controls
treble roll off, treble energy, presence energy
Enclosure
Type
Triple distributed port
Connectors
5 x 4 mm 24ct Tannoy customized binding posts
Dimensions HWD
650.2 x 424.9 x 1033.5 mm (25.6 x 16.7 x 40.7")
Net weight
50 kg (110.2 lbs)
Construction
19 mm (3/4") Particle Board, MDF with plywood internal bracing - heavily damped
Finish
Walnut veneer and high acoustic transparency nylon grill cover
Accessory pack (included)
Bi-wire bridge connectors
Tannoy High End Loudspeaker Wood Wax
Adjustable feet
