TECH SPECS
POWER OUTPUT
85 watts (into 8Ω)
THD (UNWEIGHTED)
<0.01% @ 1kHz, 80% of rated power <0.15% 20Hz - 20kHz, 80% of rated power
FREQUENCY RESPONSE (-1DB)
5Hz - 50kHz
S/N RATIO (REF 1W)
>82dB (unweighted)
INPUT IMPEDANCES
47k ohms
POWER AMP DAMPING FACTOR
>50
STANDBY POWER CONSUMPTION
<0.5W
MAX. POWER CONSUMPTION
500W
BASS/TREBLE CONTROLS
Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 20kHz
SUBWOOFER OUTPUT
200Hz 2nd order L+R Level follows volume setting
DIMENSIONS
110 x 430 x 340mm (4.3 x 16.9 x 13.4”)
WEIGHT
8.1kg (17.8lbs)
BLUETOOTH
5.0 A2DP/AVRCP supporting SBC
TUNER BANDS
European AM (522-1629kHz) FM (87.5-108MHz) / US AM (530-1710kHz) FM (87.5-108MHz)
AERIAL INPUTS
FM 75 ohms, Coaxial. AM 300 ohms wire loop/ single wire
SIGNAL TO NOISE (TUNER)
60dB typical (FM)
DISTORTION (TUNER)
<0.4% @ 1kHz 50kHz deviation (FM mono) <0.6% @ 1kHz 50kHz deviation (FM stereo)
IN THE BOX
AXR85 Stereo Receiver, Power Cable, Remote Control, 2 x AAA Batteries
