Specifications
CONNECTIVITY
Multi-Channel Outputs Balanced
0
Multi-Channel Inputs Unbalanced
0
Multi-Channel Outputs Unbalanced
11.2
Stereo Inputs Balanced
0
Stereo Inputs Unbalanced
0
Stereo Outputs Unbalanced
0
Digital Coaxial Input
2
Digital Coaxial Output
0
Digital Optical Input
2
AES/EBU Balanced Input
0
HDMI Input
4
HDMI Output
1
USB
1 Type A
Component Input
0
Component Output
0
Composite Input
0
Composite Output
0
Subwoofer 2 Output
Yes
(discrete signal from subwoofer 1)
Network Connection
1
Max # of audio channels in Zone A
11.2
Additional Zone Outputs
0
Advanced Connections
Ethernet Web interface and firmware update, IP-based control
HDMI FEATURES
Resolution and Refresh Rates
8K/60Hz and 4K/120Hz
HDCP
2.3
4:4:4 Color
Yes
Rec. 2020 (BT.2020)
Yes
3D video pass-through
Yes
Dynamic Lip-sync
No
ARC
Yes
eARC
Yes
Video Scaling
No
High Dynamic Range (HDR)
Dolby Vision, HDR10+ and HLG
Quick Media Switching (QMS)
No
Auto Low Latency Mode (ALLM)
No
Quick Frame Transport (QFT)
No
Variable Refresh Rate (VRR)
No
PROCESSING
Total Harmonic Distortion (DSP Bypass)
Available March 2023
Dolby Processing
Dolby Atmos, Dolby Surround Upmixer
DTS Processing
DTS-X, Neural:X Surround Upmixer
Auro Processing
No
Pure Stereo DSP Bypass Mode
No
MPEG-H Audio
No
360 Reality Audio
No
IMAX Enhanced
No
Room Correction
Dirac Live
ELECTRONIC SPECIFICATIONS
Power Output per Channel
150 Watts into 4 Ohms with ALL Channels Driven
120 Watts into 8 Ohms with ALL Channels Driven
Number of Channels
7.2 (expandable to 7.2.4)
Total Harmonic Distortion
Available March 2023
S/N below rated output
Available March 2023
Dynamic Headroom
Available March 2023
Damping Factor
Available March 2023
Rated Power Band
Available March 2023
Frequency Response
Available March 2023
CONTROL
Third Party Control
RS232, Web IP, IR Input
Tone Controls
Bass and Treble
OSD Overlay on HDMI Output
Volume Only
Input-Output Format Indicators
0
Control of McIntosh Sources
Yes, by handheld remote, 1 Data Out, 2 Power Control Trigger jacks
GENERAL SPECIFICATIONS
Channel Formats
7.2 (5.2.2), 7.1, 5.1, Stereo (expandable to 7.2.4)
Microphone and stand included
Yes
Network Features
Ethernet Setup
Unique Crossover Frequency, Each Speaker
Yes
Special Features
FM Tuner
Rear panel USB for firmware updating
Circuit Configuration
Closed loop digital switching
Circuit Design
Digital
Output Type
Direct Coupled
BTU Rating
Available March 2023
WEIGHTS & DIMENSIONS
Unit Dimensions (W x H x D)
Available March 2023
Unit Weight
Available March 2023
Shipping Weight
Available March 2023
