Technical Specifications
Power Amplifier
Number of Powered Channels 7
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 50 W
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) -
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 70 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 100 W
70% Guarantee Yes
Discrete Power Amplifier Yes
Amplifier Topology Class A/B
Current Feedback Topology No
Bi-Amp Drive assignable
Multichannel Surround Technologies
DTS DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Other
Max Number of Processing (Preamp) Channels 7.1
Inputs/Outputs
Composite In / Out 0 / 0
Component In / Out 0 / 0
HDMI In / Out 6 / 1
Multi-Room Video Out via HDMI No
Analog In / Fixed Level Out 3 in / 0 out
Phono (MM) In Yes
Digital In: Optical / Coaxial 1 / 1
Multi-Room Out: analog / digital 1 / 0
Multichannel Preamp Out 7.2
Subwoofer Out 2
7.1 multichannel input No
Number of Speaker Terminals 7
Speaker A / B assignable
Multi-Room Speaker Terminal assignable
Front Inputs USB-A
USB Audio / Made for iPod / Made for iPhone Yes / No / No
AM/FM Tuner Yes
HDMI
Total HDMI Inputs / No. Support 8K 6 / 3
HDCP2.3 support Yes
HDMI Outputs: Main / Zone 1 / 0
Analog to HDMI Video Conversion No
HDMI Upscaling 1080P/4K to 8K
Max resolution @ framerate 8K/60Hz, 4K/120Hz
Audio Return Channel ARC, eARC
Video Dynamic Range HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming Yes
Variable Refresh Rate / Quick Frame Transport Yes / Yes
HDMI Pass-Through in Standby Mode Yes
CEC Yes
DSD Audio over HDMI No
Auto LipSync Yes
Performance Technologies
Copper Plated Chassis No
Toroidal Power Supply Transformer No
Hyper Dynamic Amplifier Modules (HDAM) (List version) No
Pure Direct Mode Yes
Gold Plated RCA Terminals No
Clock Jitter Reducer No
Acoustic / Room Correction
Audyssey MultEQ
Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
Audyssey LFC No
Dirac Live Support No
Variable Cross Over Yes
Optimized Bass Redirection Yes
Bass Sync No
Music File Support
Lossy Formats MP3 / WMA / AAC
Lossless formats FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio 2.8 MHz / 5.6 MHz
Gapless Playback FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2 Yes
Network Audio Sharing Yes
Streaming Services
HEOS Multi-room and Streaming Yes
AirPlay Audio Streaming AirPlay 2
Internet Radio TuneIn
Spotify* Spotify Connect
Pandora Yes
SiriusXM Yes
Other Streaming Services * Amazon Music HD/
Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
Roon tested Yes
Network Connectivity
Ethernet Ports Yes
Wi-Fi (include version / band) Yes
Bluetooth (Include version) Yes
Bluetooth Re-transmit for Bluetooth headphones Yes
Smart Home Integration And Control
Others
Front Display port hole OLED
GUI Languages 3
Setup Assistant Yes
Smart Select on Remote Yes
Firmware Update by Network / USB Yes / Yes
ECO Mode Yes
Auto Power off Yes
Sleep Timer Yes
General
Available Colors Black
Metal Front Panel No
System Remote Control RC050SR
Power Consumption in W 250
Power Consumption No-Sound (ECO on/off) in W 30 / 40
Standby Consumption in W 0.2
CEC Standby Consumption in W 0.5
Network Standby Consumption in W Less than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in inches
Antenna:Vertical :(W x D x H) in inches
W/o Antenna:(W x D x H) in inches 17.4 x 15.1 x 4.3
17.4 x 15.1 x 7.0
17.4 x 14.7 x 4.3
Weight in lbs. 19.2
What's in the box Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
